Fold-Over Hinge Most Comet mobile antennas over 29" length have a fold-over hinge built into the base section of the antenna. It is NOT an automatic fold-over, you must manually lift the element up out of the socket and lay the antenna whip down in order to enter garages, parking structures etc...
Like any hinge, it will BREAK if it is folded the wrong direction. The hinge rotates 360 deg inside the socket so it will fold in the direction needed. Many Chinese and other look-a-like antennas have very annoying problems associated with their fold-over hinges. The most common is a weak spring. The antena lifts up and out of the socket all by itself at highway speeds! The antenna is unusable when it is laying down and most users need to defeat the hinge or constantly adjust the angle to keep it vertical. And to be honest, Comet had this problem "initially" as well! The weak spring was almost always a problem with the larger antennas so Comet engineers went to work and re-designed the fold-over. Our larger antennas now have a threaded collar around the hinge: Loosen the collar, lift it up, and the hinge is exposed. No more problem. |
It is important that you lift the whip completely up and out of the socket before folding the hinge.
| Comet Single Band Mobile Antenna | ||||
| Click to Enlarge | Part Number | Desc | Price | Buy |
 |
SBB-123 | Single-band 1240-1300MHz mobile antenna, great for D-STAR Gain & Wave: 7.2dBi 5/8 wave x 3, VSWR: 1.5:1 or less, Max Pwr: 50 watts, Length: 24", Color Black, Fold-over hinge included, Connector: N-Type | $54.00 | |
 |
SBB-25 | The SBB-25 is the best 2M mobile antenna COMET has to offer. The radiation pattern provides the best possible signal strength and coverage area. Gain & Wave: 4.1dBi, center-load 5/8 wave, VSWR: 1.5:1 or less, Max Pwr: 200 watts, Length: 57", Fold-over hinge included, Connector: PL-259 | $49.00 | |
|
SBB-25NMO | The SBB-25 is the best 2M mobile antenna COMET has to offer. The radiation pattern provides the best possible signal strength and coverage area. Gain & Wave: 4.1dBi, center-load 5/8 wave, VSWR: 1.5:1 or less, Max Pwr: 200 watts, Length: 57", Fold-over hinge included, Connector: NMO | $49.00 | |
 |
SF-245SPR-R | Mobile 802.11b,g Wi-Fi Antenna, 2.4GHz. For Used in 2.4GHz mobile public service safety projects worldwide. Provides excellent signal strength in metro scale Wi-Fi installations. Gain & Wavelength: 7.4dBi 1/2wave x 5, VSWR: 1.5:1 or less, Max Power: 50 watts, Length: 18", Construction: Fiberglass radome, with spring base. Connector: N-male. Note: For magnet mounting, choose the MG-4N | $59.00 | |
| Comet Dual Band Mobile Antenna | ||||
| Click to Enlarge | Part Number | Desc | Price | Buy |
 |
B-10 | DualBand 146/440MHz, Gain & Wave: 146MHz -dBi 1/4 wave 446MHz 2.15dBi 1/2 wave, VSWR: 1.5:1 or less, Max Power: 50 watts, Length: 12", Connector: PL-259 | $42.00 | |
|
B-10NMO | DualBand 146/440MHz, Gain & Wave: 146MHz -dBi 1/4 wave 446MHz 2.15dBi 1/2 wave, VSWR: 1.5:1 or less, Max Power: 50 watts, Length: 12", Connector: NMO | $42.00 | |
 |
CA-2x4SR | BROADBAND VHF/UHF Dual Band Antenna. Designed to assist Search &
Rescue Volunteers and Professionals, SWR: 1.5:1 or less Gain: 140-160/435-465MHz 3.8/6.2dBi, Max
Power: 150 watts, Length: 40 inches, Fold-over hinge included, Connector: PL-259
The CA-2x4SR is a broad-band antenna designed for those needing voice communications on the ham radio, land mobile, FRS, MURS, and most GMRS frequency ranges. When the amateur radio community is working together with local search and rescue and other public service agencies, the CA-2x4SR antenna allows TX and RX capability in both bands! The coverage area and gain provided by the CA-2x4SR is remarkable. Whether used on VHF or UHF or both, it is an asset to the communications needs of amateurs and land mobile users simultaneously. |
$59.95 | |
|
CA-2x4SRNMO | BROADBAND VHF/UHF Dual Band Antenna. Designed to assist Search &
Rescue Volunteers and Professionals, SWR: 1.5:1 or less Gain: 140-160/435-465MHz 3.8/6.2dBi, Max
Power: 150 watts, Length: 40 inches, Fold-over hinge included, Connector: NMO
The CA-2x4SR is a broad-band antenna designed for those needing voice communications on the ham radio, land mobile, FRS, MURS, and most GMRS frequency ranges. When the amateur radio community is working together with local search and rescue and other public service agencies, the CA-2x4SR antenna allows TX and RX capability in both bands! The coverage area and gain provided by the CA-2x4SR is remarkable. Whether used on VHF or UHF or both, it is an asset to the communications needs of amateurs and land mobile users simultaneously. |
$59.95 | |
 |
CA-SPR | Optional spring for CA-2x4SR antenna | $19.95 | |
 |
CSB-750A | Comet's BEST DualBand Mobile Antenna 2M/440MHz high gain antenna, Gain& Wave: 2M 1/2 wave 3.6dBi 440MHz Two 5/8 waves 6.1dBi, VSWR: 1.5:1 or less, Max Power: 150W Length: 42", Fold-over hinge included, Connector: Gold-plated PL-259 | $61.95 | |
 |
CSB-770A | Comet's BEST DualBand Mobile Antenna 2M/440MHz high gain antenna Gain& Wave: 2M 5/8 wave 4.4dBi 440MHz Two 5/8 waves 6.9dBi, VSWR: 1.5:1 or less, Max Power: 150W Length: 50", Fold-over hinge included, Connector: Gold-plated PL-259 | $73.00 | |
 |
CSB-790A | Comet's NEWEST & BEST high gain 2M/440MHz dualband mobile antenna, Gain & Wavelength: 2M: 7/8 wave 5.1dBi 440MHz: 7.7dBi Three 5/8 waves in phase, VSWR: 1.5:1 or less, Max Power: 150W, Length: 62", Threaded collar fold-over hinge included, Connector: Gold-plated PL-259 | $94.95 | |
 |
HP-32FHN | 146/446Mhz Heavy Duty, High Power Dual Band Mobile Antenna, Gain & Wave: 146MHz 3dBi 1/2 wave 446MHz 5.5dBi 5/8 wave x 2, VSWR: 1.5:1 or less, Max power: VHF: 350 watts UHF: 250 watts, Length: 35 inches, Fold-over hinge included, Connector: PL-259 | $73.50 | |
 |
MA-721 | Compact 2M/70cm DualBand Mag-Mount Antenna, Gain & Wave: 2M: 1.7dBi 3/8 wave 440MHz: 4.1dBi 1/4 + 5/8 wave, VSWR: 1.5:1 or less, Max Power: 80 watts, Length: 19.5", Coax: RG-58A/U x 16.5ft, PL-259 and SMA Male connectors. Info Sheet | $39.00 | |
 |
SBB-1 | Flexible (rubber coated element) DualBand 146/446MHz, Gain & Wave: 146MHz 1.5dBi 1/4 wave 446MHz 2.15dBi 1/2 wave, VSWR: 1.5:1 or less, Max Power: 60 watts, Length: 16" Connector: Gold-Plated PL-259 | $44.95 | |
|
SBB-1NMO | Flexible (rubber coated element) DualBand 146/446MHz, Gain & Wave: 146MHz 1.5dBi 1/4 wave 446MHz 2.15dBi 1/2 wave, VSWR: 1.5:1 or less, Max Power: 60 watts, Length: 16" Connector: Gold-Plated NMO | $44.95 | |
 |
SBB-2 | DualBand 2M/70cm mobile antenna, Gain & Wavelength: 2M 2.15dBi 1/4 wave 70cm: 3.8dBi 5/8 wave, VSWR: 1.5:1 or less, Max Power: 60 watts, Length: 18", Connector: Gold-plated PL-259 | $35.50 | |
|
SBB-2NMO | DualBand 2M/70cm mobile antenna, Gain & Wavelength: 2M 2.15dBi 1/4 wave 70cm: 3.8dBi 5/8 wave, VSWR: 1.5:1 or less, Max Power: 60 watts, Length: 18", Connector: Gold-plated NMO | $35.50 | |
 |
SBB-5 | DualBand 2M/70cm mobile antenna, This is the most popular antenna in the Comet line for several reasons: Mid-size - mid-price range - open coil bends to absorb brushes with tree branches - black color fades into the skyline - ground independent, Gain & Wavelength: 146MHz 3.0dBi 1/2 wave 446MHz 5.5dBi 5/8 wave x 2, VSWR: 1.5:1 or less, Max Power: 120W FM, Length: 38", Connector: Gold-plated PL-259 | $47.50 | |
 |
SBB-5NMO | DualBand 2M/70cm mobile antenna, This is the most popular antenna in the Comet line for several reasons: Mid-size - mid-price range - open coil bends to absorb brushes with tree branches - black color fades into the skyline - ground independent, Gain & Wavelength: 146MHz 3.0dBi 1/2 wave 446MHz 5.5dBi 5/8 wave x 2, VSWR: 1.5:1 or less, Max Power: 120W FM, Length: 38", Connector: Gold-plated NMO | $47.50 | |
 |
SBB-7 | DualBand 2M/70cm mobile antenna, Gain & Wavelength: 2M: 4.5dBi 6/8 wave center-load 70cm: 7.2dBi 5/8 wave x 3, VSWR: 1.5:1 or less, Max Power: 70W FM, Length: 55", Connector: Gold-plated PL-259 | $59.95 | |
|
SBB-7NMO | DualBand 2M/70cm mobile antenna, Gain & Wavelength: 2M: 4.5dBi 6/8 wave center-load 70cm: 7.2dBi 5/8 wave x 3, VSWR: 1.5:1 or less, Max Power: 70W FM, Length: 55", Connector: Gold-plated NMO | $64.50 | |
 |
SS-460SB | DualBand 2M/70cm mobile antenna, Gain: 2M: 2.15dBi 70cm: 3.8dBi, VSWR: 1.5:1 or less, Max Power: 60W, Length: 18", Built in spring, Connector: PL-259 | $38.95 | |
 |
SS-460SBNMO | DualBand 2M/70cm mobile antenna, Gain: 2M: 2.15dBi 70cm: 3.8dBi, VSWR: 1.5:1 or less, Max Power: 60W, Length: 18", Built in spring, Connector: NMO | $38.95 | |
 |
SS-680SB | DualBand 2M/70cm mobile antenna, Gain: 2M: 2.15dBi 70cm: 4.15dBi, VSWR: 1.5:1 or less, Max Power: 80W, Length: 27", Built in spring, Connector: PL-259 | $39.95 | |
|
SS-680SBNMO | DualBand 2M/70cm mobile antenna, Gain: 2M: 2.15dBi 70cm: 4.15dBi, VSWR: 1.5:1 or less, Max Power: 80W, Length: 27", Built in spring, Connector: NMO | $39.95 | |
| Comet Tri Band Mobile Antenna | ||||
| Click to Enlarge | Part Number | Desc | Price | Buy |
 |
SBB-15 | Tri-Band Mobile Antenna 50/146/446MHz, Gain & Wave: 50MHz 2.15 1/4 wave 146MHz 4.5dBi 5/8 wave 446MHz 7.2dBi 5/8 wave x 3, VSWR: 1.5:1 or less, Max Power: 120 watts, Length: 61", fold-over hinge included, Connector: PL-259 | $76.00 | |
 |
SBB-224 | Tri-Band 146/220/446MHz, Gain & Wave: 146MHz 2.15dBi 1/4 wave 220MHz 3.5dBi 5/8 wave 446MHz 6.0dBi 5/8 wave x 2, VSWR: 1.5:1 or less, Max Power: 100 watts, Length: 36", Connector: PL-259 | $78.00 | |
|
SBB-224NMO | Tri-Band 146/220/446MHz, Gain & Wave: 146MHz 2.15dBi 1/4 wave 220MHz 3.5dBi 5/8 wave 446MHz 6.0dBi 5/8 wave x 2, VSWR: 1.5:1 or less, Max Power: 100 watts, Length: 36", Connector: NMO | $78.00 | |
